105SL Parts Catalog
Drive System Components
Item
Number
Description Part Number
Kit
Quantity
1 Kit DC Stepper Motor w/Pulley 203 DPI G46198M 1
1 Kit DC Stepper Motor w/Pulley 300 DPI G46199M 1
2 Main Drive Belt 45189-5 1
3 Media Rewind Belt 45189-2 1
4 Kit Platen Pulley 40355M 1
5 Kit Peel Roller Pulley 30914M 1
6 Kit Pulley for Media Take Up & Ribbon Take Up 31336M 1
7 Rewind Idler Pulley 30265 1
Idler Pulley Shaft 30207 1
4
